HD107S RGB Pixel Digital LED Strip Lights
LED Light Source: 5050 SMD LED,
Viewing angle: 120 degrees
Working voltage: DC5V
Color: White, Warm white, Natural white, Red, Green, Blue, Yellow,
PCB Width: 12mm
PCB color: White/Black
LED Quantity per meter:30LED 60LED 144LED
Waterproof rate: IP20, IP65, IP67
Waterproof method: Surface Epoxy Plated, Silicone Pipe, Full
Working temperature: -20~+60 celsius degree
Packing: 5m/roll, 1roll/bag
HD107S will be upgraded again, the PWM can be 26-28kHz, faster and
cheaper than APA102.
HD107S is a type ic for the three-color RGB Diming control strip
and string ,This ic using the CMOS process to provide three-color
RGB LED output driver to adjust the output with 256 gray scale and
32 brightness adjustment, APA107 with 2 signal output way, one is
clock ,another is data, the clock and data is synchronizated,so
that the crystal cascade piece of output movement is sychronizated.
1, Control IC included,supporting numerous color-change effects.
2, Absolutely addressable,each IC built inside RGB LED.
3, Each IC control one leds.
4, h107s have 4 Wire input and output : Data ,Clock ,GND ,Anode,
build in ic, double signal .
5, Grey scale 256, 256(Red)*256(Green)*256(Blue) colors that APA107
LED can change to. Keep LED show smooth color effect when changing
OPTICAL PARAMETERBASIC PARAMETER
LED Q’ty: 30LEDs/m, Pixels: 30/m , Gray Scale:256
Power/m: 9W, Input voltage: DC5V, Max current/LED: 60Ma, Warranty:
Illumination Angle: 120° , Working temperature: -20℃~+45℃, Working
Energy grade: A, SMD LED spacing: 33.08mm, CRI(Ra): >80Ra
Minim cuttable length: every LED is cuttable, PCB Width: 10mm
The upgraded type of HD107S Pixel Digital LED Strip Lights.
APA107 LED Strip Connections:
Indoor and outdoor decoration lightings.
Idea for in advertisement and cabaret, large scale backlight,
cabinet, furniture, landscape outlines
Edge-lighting of transparent or diffused materials, to couple light
into transparent or diffused glass
Bridge edge lighting
Window display lighting
Car and motorcycle decorative lighting
Path & Building contour decorative lighting
Emergency hallway lighting / rescue signs / advertising signs /
Architectural decorative lighting, villa, restaurant, hotel,
meeting room, show room, shop, counter, etc
Festival lighting, General lighting, Task lighting, Household
appliances, Architectural lighting, Decorative / pathway lighting,
Switch off power of the mains supply or respectively of the
connection lead before doing any works.
The complete installation must be done by an electrical expert who
is familiar with the valid directives.Quaity Control
Stability TEST: make sure 100% of the lamps be aging test at least
Lighting TEST: make sure 100% of the lamps be lighted before
Drop TEST: make sure every single light have been well protected by
